Air flow performance you can count on
July 24, 2024  |  share:

The innovative Jetline range sets a new benchmark for low profile in-line centrifugal fans. They feature fully integrated guide vanes that increase pressure development, and a patented centrifugal impeller that maximises air flow performance. Its durable outer casing and quick fit mounting bracket are manufactured from galvanised metal which ensures a long working life.

Available in models with AC and EC motors

Jetline fans include silent-block motor mounts to reduce vibration and lower operating noise levels. They are quick to install and feature a cleverly designed terminal box and mounting bracket that won’t increase the overall height of the fan profile. Jetline fans are available in AC and an energy efficient, electronically commutated (EC) model that can be speed controlled via a 0-10 V analogue input signal.

The Jetline fan is fitted with a rubber gasket on the spigots that improves the seal between the fan and duct work connection. It’s compact design makes it ideal for a wide range of residential and commercial applications such as apartments and hotels that have limited ceiling spaces.

Key Features

  • 6 fan sizes: Suits 100, 125, 150, 200, 250 and 315mm duct diameters
  • Speed controllable with optional VA speed controllers (AC) or 0-10V analogue input signal (EC)
  • Optimised impeller, guide vanes and outlet diffuser for low noise operation
  • Low profile, durable outer casing manufactured from galvanised sheet metal
  • Robust, galvanised metal quick fit mounting bracket for fast installations
  • Junction box can be positioned on either side of the fan.
  • Rated IP44
